Description
Part Number: DHIPD50/28LRW/30-D-V4
Brand: SPRO
Camera Resolution 5 Megapixels
Lens Fixed Lens
Codec recording H.265
IR Distance Up to 30m IR distance
LED Distance Up to 30m LED distance
Built-in Mic. Yes
Speaker Built-in Yes
Siren Built-in Yes
2 Way Audio Microphone & Speaker Built-in
Audio over CAT5e Yes
Active Deterrence Yes
Colour Night Yes
SMD (Smart Motion Detection) Yes
Perimeter Protection Yes
Tripwire Yes
Intrusion Yes
WDR 120dB
Style Turret
AcuPick Yes
The SPRO Smart Dual Illumination Active Deterrence camera series is designed to proactively deter crime with its advanced features. With red and blue flashing lights, a two-way audio system, and pre-recorded messages, this camera is sure to enhance your security measures. Plus, you can trust its meticulous craftsmanship for top-quality performance.
Our advanced technology features, including AcuPick and Colour Night 2.0, redefine nighttime surveillance to deliver stunning, full-color images in low-light conditions. Plus, the white light LED inclusion guarantees the perfect level of scene illumination for any situation.
Key Features:
-
5 megapixel
-
H.265
-
2.8mm Lens
-
Up to 30m LED distance (smart LED)
-
Up to 30m IR distance (smart LED)
-
SMD 4.0 (Smart motion detection)
-
Intrusion (human & vehicle classification)
-
Tripwire (human & vehicle classification)
-
Two-way-audio
-
Microphone built-in (audio over CAT5e cable)
-
120dB WDR
-
IP67 waterproof
- DC 12V/POE
| Specifications: | |
|---|---|
| Model Number | DHIPD50/28LRW/30-D-V4 |
| Image Sensor | 1/2.7” CMOS |
| Effective Pixels | 2960 (H) x 1668 (V) |
| ROM | 128 MB |
| RAM | 512 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.003 lux@F1.0 (Colour, 30 IRE) 0.0003 lux@F1.0 (B/W, 30 IRE) 0 lux (illuminator on) |
| S/N Ratio | ＞56 dB |
| Illumination Distance | 30 m (98.43 ft) (IR) 30 m (98.43 ft) (warm light) |
| Illuminator On/Off Control | Auto / Manual |
| Illuminator Number | 1 (IR LED) 1 (warm light) |
| Pan/ Tilt/ Rotation Range | Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed focal |
| Mount Type | M12 |
| Focal Length | 2.8mm |
| Field of View | Horizontal: 97°; vertical: 70°; diagonal: 128° |
| Iris Type | Fixed |
| Close Focus Distance | 1.5 m (4.92 ft) |
| DORI Distance | Detect: 66 m Observe: 26.4 m Recognise: 13.2 m Identify: 6.6 m |
| Intelligence | |
| IVS (Perimeter Protection) | Tripwire; intrusion (Recognition of human and vehicle) |
| SMD 4.0 | Less false alarm, longer detection distance. |
| Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| AI SSA | Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions. |
| Video | |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| AI Coding | AI H.265; AI H.264 |
| Video Frame Rate | Main stream: 2880 × 1620/2960 × 1668@(1 fps–20 fps)/2688 × 1520 @(1 fps–30 fps) Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps) Third stream: 1920 × 1080@(1 fps–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Streaming Capability | 3 Streams |
| Resolution | 5M (2880 × 1620/2960 × 1668); 4M (2688 × 1520/2560 × 1440); 3M 2304×1296/2048 × 1536); 1080p (1920×1080); 1.3M (1280 × 960); 720P(1280×720); D1 (704× 576/704×480); VGA(640 × 480); CIF (352×288/352×240) |
| Bit Rate Control | CBR / VBR |
| Video Bit Rate | H.264: 32kbps - 8192 kbps; H.265: 12kbps-8192 kbps |
| Day/Night | Auto (ICR)/Colour/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| Scene Self-adaptation | Yes |
| White Balance | Auto / Natural / Street Lamp / Outdoor / Manual / regional custom |
| Gain Control | Auto/ Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 8 Areas |
| Audio | |
| Built-in MIC | Yes, built-in dual Mic |
| Built-in Speaker | Yes, built-in dual Speaker |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm | |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| SDK and API | Yes |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P |
| Interoperability | ONVIF (Profile S;Profile G;Profile T); CGI |
| Max. User Access | 20 (Total bandwidth: 72 M) |
| Storage | FTP; SFTP; Micro SD card (Support max. 256Gb); NAS |
| Web Viewer | IE: IE8/9/11; Chrome; Firefox |
| Management Software | DMSS |
| Smart Phone | iOS; Android |
| Certification | |
| Certification | CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port | |
| Audio Input | 1 channel (RCA port) |
| Audio Output | 1 channel (RCA port) |
| Alarm Input | 1 channel in: 5mA 3V–5V DC |
| Alarm Output | 1 channel out: 300mA 12V DC |
| General | |
| Power Supply | DC12V, POE |
| Power Consumption | Basic: 3.7W (12 VDC); 4.8W (PoE) Max. (pulling stream+warning light+speaker+warm light on): 8.3W (DC12 V) 8.8W (POE) |
| Operating Conditions | –40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH |
| Storage Conditions | –40 °C to +60 °C (–40 °F to +140 °F) |
| Ingress Protection | IP67 |
| Casing | Metal |
| Dimensions | 110.9 mm × Φ122.0 mm (4.37" × Φ4.80") |
| Net Weight | 754g |
| Gross Weight | 915g |
Description
Part Number: DHIPD50/28LRW/30-D-V4
Brand: SPRO
Camera Resolution 5 Megapixels
Lens Fixed Lens
Codec recording H.265
IR Distance Up to 30m IR distance
LED Distance Up to 30m LED distance
Built-in Mic. Yes
Speaker Built-in Yes
Siren Built-in Yes
2 Way Audio Microphone & Speaker Built-in
Audio over CAT5e Yes
Active Deterrence Yes
Colour Night Yes
SMD (Smart Motion Detection) Yes
Perimeter Protection Yes
Tripwire Yes
Intrusion Yes
WDR 120dB
Style Turret
AcuPick Yes
The SPRO Smart Dual Illumination Active Deterrence camera series is designed to proactively deter crime with its advanced features. With red and blue flashing lights, a two-way audio system, and pre-recorded messages, this camera is sure to enhance your security measures. Plus, you can trust its meticulous craftsmanship for top-quality performance.
Our advanced technology features, including AcuPick and Colour Night 2.0, redefine nighttime surveillance to deliver stunning, full-color images in low-light conditions. Plus, the white light LED inclusion guarantees the perfect level of scene illumination for any situation.
Key Features:
-
5 megapixel
-
H.265
-
2.8mm Lens
-
Up to 30m LED distance (smart LED)
-
Up to 30m IR distance (smart LED)
-
SMD 4.0 (Smart motion detection)
-
Intrusion (human & vehicle classification)
-
Tripwire (human & vehicle classification)
-
Two-way-audio
-
Microphone built-in (audio over CAT5e cable)
-
120dB WDR
-
IP67 waterproof
- DC 12V/POE
| Specifications: | |
|---|---|
| Model Number | DHIPD50/28LRW/30-D-V4 |
| Image Sensor | 1/2.7” CMOS |
| Effective Pixels | 2960 (H) x 1668 (V) |
| ROM | 128 MB |
| RAM | 512 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.003 lux@F1.0 (Colour, 30 IRE) 0.0003 lux@F1.0 (B/W, 30 IRE) 0 lux (illuminator on) |
| S/N Ratio | ＞56 dB |
| Illumination Distance | 30 m (98.43 ft) (IR) 30 m (98.43 ft) (warm light) |
| Illuminator On/Off Control | Auto / Manual |
| Illuminator Number | 1 (IR LED) 1 (warm light) |
| Pan/ Tilt/ Rotation Range | Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed focal |
| Mount Type | M12 |
| Focal Length | 2.8mm |
| Field of View | Horizontal: 97°; vertical: 70°; diagonal: 128° |
| Iris Type | Fixed |
| Close Focus Distance | 1.5 m (4.92 ft) |
| DORI Distance | Detect: 66 m Observe: 26.4 m Recognise: 13.2 m Identify: 6.6 m |
| Intelligence | |
| IVS (Perimeter Protection) | Tripwire; intrusion (Recognition of human and vehicle) |
| SMD 4.0 | Less false alarm, longer detection distance. |
| Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| AI SSA | Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions. |
| Video | |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| AI Coding | AI H.265; AI H.264 |
| Video Frame Rate | Main stream: 2880 × 1620/2960 × 1668@(1 fps–20 fps)/2688 × 1520 @(1 fps–30 fps) Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps) Third stream: 1920 × 1080@(1 fps–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Streaming Capability | 3 Streams |
| Resolution | 5M (2880 × 1620/2960 × 1668); 4M (2688 × 1520/2560 × 1440); 3M 2304×1296/2048 × 1536); 1080p (1920×1080); 1.3M (1280 × 960); 720P(1280×720); D1 (704× 576/704×480); VGA(640 × 480); CIF (352×288/352×240) |
| Bit Rate Control | CBR / VBR |
| Video Bit Rate | H.264: 32kbps - 8192 kbps; H.265: 12kbps-8192 kbps |
| Day/Night | Auto (ICR)/Colour/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| Scene Self-adaptation | Yes |
| White Balance | Auto / Natural / Street Lamp / Outdoor / Manual / regional custom |
| Gain Control | Auto/ Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 8 Areas |
| Audio | |
| Built-in MIC | Yes, built-in dual Mic |
| Built-in Speaker | Yes, built-in dual Speaker |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm | |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| SDK and API | Yes |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P |
| Interoperability | ONVIF (Profile S;Profile G;Profile T); CGI |
| Max. User Access | 20 (Total bandwidth: 72 M) |
| Storage | FTP; SFTP; Micro SD card (Support max. 256Gb); NAS |
| Web Viewer | IE: IE8/9/11; Chrome; Firefox |
| Management Software | DMSS |
| Smart Phone | iOS; Android |
| Certification | |
| Certification | CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port | |
| Audio Input | 1 channel (RCA port) |
| Audio Output | 1 channel (RCA port) |
| Alarm Input | 1 channel in: 5mA 3V–5V DC |
| Alarm Output | 1 channel out: 300mA 12V DC |
| General | |
| Power Supply | DC12V, POE |
| Power Consumption | Basic: 3.7W (12 VDC); 4.8W (PoE) Max. (pulling stream+warning light+speaker+warm light on): 8.3W (DC12 V) 8.8W (POE) |
| Operating Conditions | –40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH |
| Storage Conditions | –40 °C to +60 °C (–40 °F to +140 °F) |
| Ingress Protection | IP67 |
| Casing | Metal |
| Dimensions | 110.9 mm × Φ122.0 mm (4.37" × Φ4.80") |
| Net Weight | 754g |
| Gross Weight | 915g |
SPRO
by
SPRO
SPRO 5MP IP Smart Dual Illumination Turret with Active Deterrence and Acupick Technology
- Regular price
- £149.02
- Sale price
- £149.02
- Regular price
-
£169.99
Tax included.
