About
Description
Part Number: DHDVR24-B5-V3-0TB
Recorder Resolution 5MP-Lite
SMD (Smart Motion Detection) Yes
Perimeter Protection Yes
Tripwire Yes
Intrusion Yes
Face detection Yes
Extra IP Channels 8 Channel
Smart Dual Illumination Supported Yes
The SPRO 5MP-Lite DVR incorporates cutting-edge technology and a modern design. Utilizing AI PRO, Intrusion, Tripwire, Face Detection, Perimeter Protection, and Smart Motion Detection Plus, it offers unparalleled protection and surveillance capabilities. With 16 BNC channels and the ability to add 8 more IP channels through the local network, it enables up to 24 cameras to be recorded and displayed on the device.
Key Features
- H.265 video compression
- 5M-N recording@10fps, 1080P@15fps
- Supports up to 5MP on extra IP channels
- Supports “IP Audio over CAT5e” on extra IP channels (compatible cameras required)
- P2P(no port forwarding required)
- SMD PLUS (smart motion detection plus)
- Perimeter protection- Intrusion & tripwire (human & vehicle classification)
- Face detection 2.0- 2 way audio
- Push notification
- Spot monitoring via local network
| Specifications: | |
|---|---|
| Model Number | DHDVR24-B5-V3 |
| Main Processor | Embedded Processor |
| Operating System | Web; Local GUI |
| Perimeter Protection | |
| Performance | Advanced Model: 2 channel, 10 IVS for each channel General Model: 4 channels, 10 IVS for each channel |
| Face Detection | |
| Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance AI by Recorder |
2 channels (up to 12 face images/s) |
| Face Recognition | |
| Face Database Capacity | Up to 10 face databases with 10000 face images in total. Name, gender, birthday, address, certificate type, certificate No., countries & regions and state can be added to each face picture |
| Face Recognition Performance AI by Recorder |
2channels |
| SMD Plus | |
| SMD Plus by Recorder | 16 channels: Secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change |
| Audio and Video | |
| Analogue Camera Input | 16 BNC ports, CVI access by default, supports HDCVI/AHD/TVI/CVBS auto-detect |
| Camera Input | 1. CVI: 5MP, 4MP, 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps. 2. TVI: 5MP, 4MP, 3MP, 1080p@25/30, 720p@25/30 fps. 3. AHD: 5MP, 4MP, 3MP, 1080p@25/30, 720p@25/30 fps. |
| IP Camera Input | Up to 24 channels of IPC access 8 IP channels by default + 16 channels (analogue channels are converted to IP channels) incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled. |
| Encoding Capacity | Main stream: All channel 5M-N (1 fps–10 fps); 4M-N/1080p (1 fps–15 fps); 1080N/720p/960H/D1/CIF (1 fps–25/30 fps) Sub stream: Supported (D1/CIF (1 fps–15 fps)). |
| Dual-stream | Yes |
| Video Frame Rate | PAL: 1fps-25fps NTSC: 1fps-30fps |
| Video Bit Rate | 32Kbps-6144Kbps Per Channel |
| Audio Sampling | 8KHz, 16 bit |
| Audio Bit Rate | 64kbps |
| Video Output | 1 HDMI ,1 VGA VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 It changes to 1920 × 1080, 1280 × 1024, 1280 × 720 when Face or IVS&SMD is selected in AI Mode. |
| Multi-screen Display | When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled: 1/4/8/9/16/25 |
| Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Samsung |
| Compression Standard | |
| Video Compression | AI Coding / H.265+ / H.265 / H.264+ / H.264 |
| Audio Compression | G.711a; G.711u; PCM |
| Network | |
| Network Protocol | HTTP, HTTPS, TCP / IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P |
| Mobile Phone Access | iPhone, iPad, Android |
| Interoperability | ONVIF 21.03, CGI |
| Browser | Chrome, IE9 or later, Firefox |
| Network Mode | Single-address mode |
| Recording Playback | |
| Record Mode | General, motion detection; intelligent; alarm; POS |
| Record Playback | 1/4/9/16 It changes to 1/4/9 split when Face or IVS&SMD is selected in AI Mode |
| Backup Method | USB Device / Network |
| Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Alarm | |
| General Alarm | Motion detection; video loss; tampering; local alarm |
| Anomaly Alarm | No disk, disk error, low space, offline, ip conflict, MAC conflict |
| Intelligent Alarm | Face detection, face recognition, perimeter protection |
| Alarm Linkage | Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email |
| Ports | |
| TV Output | 1-channel RCA (external) 16-channel BNC (coaxial audio) |
| Audio Input | 1-channel RCA |
| Two-way Talk | Yes (share the same audio input with the first channel) |
| HDD Interface | 1 SATA Port, up to 16TB, the maximum HDD capacity varies with environment temperature |
| RS-485 | 1 port, for PTZ control |
| USB | 2 (1 front USB port, 1 rear USB 3.0 port) |
| HDMI | 1 |
| VGA | 1 |
| Network Port | 1 (10/100/1000Mbps Ethernet port, RJ-45) |
| General | |
| Power Supply | 12 VDC, 2 A |
| Power Consumption | Lower than 12 W |
| Net Weight | 1.17 kg (2.58lb) |
| Gross Weight | 1.57 kg (3.46lb) |
| Product Dimensions | Compact 1U, 260.0 mm × 237.9 mm × 47.6 mm 10.24" × 9.37" × 1.87" (W × D × H) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity | 10%–90% |
| Installation | Desktop |
| Certification | |
| Certifications | CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 FCC: Part 15 Subpart B |
